7 Parameter reference
7.1 Parameter list | C15000
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C15000
C15002
Parameter | Name:
C15000 | Status of safety functions
Data type: BITFIELD_32
Index: 9575
d
= 2567
h
Bit-coded status word of the safety functions
Display range
(min. hex value | max. hex value)
Value is bit-coded: Information
Bit 0 STO active  Safe torque off (STO)
Bit 1 SS1 active  Safe stop 1 (SS1)
Bit 2 Reserved
Bit 3 Reserved
Bit 4 Reserved
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
Bit 8 Reserved
Bit 9 ES active
 Enable switch (ES)
Bit 10 Reserved
Bit 11 OMS
 Operation mode selector (OMS)
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
Bit 16 Reserved
Bit 17 Reserved
Bit 18 Reserved
Bit 19 Reserved
Bit 20 Reserved
Bit 21 Reserved
Bit 22 Reserved
Bit 23 SSE active
 Emergency stop function
Bit 24 SD-In1 active
Bit 25 SD-In2 active
Bit 26 Reserved
Bit 27 Reserved
Bit 28 Reserved
Bit 29 OMS active
 Safe operation mode selector
Bit 30 Reserved
Bit 31 Error active
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C15002 | Command
Data type: UNSIGNED_8
Index: 9573
d
= 2565
h
This code is for device-internal use only and must not be written to by the user!
