Safe configuration
3.6
Safety bus
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.6
Safety bus
The drive-based safety system provides parameterisable interfaces for standardised safety bus
systems. By selecting the bus system, the corresponding parameters are made available.
Short overview of "Safety bus" parameter group:
S bus: Configuration
Selection of the safety bus system used. Communication modes that are currently being supported:
• Operation without safety bus
• Operation with PROFIsafe protocol
S bus: Filter control data
Unused functions in the control data of the safety bus must be set to "Inhibit" via this parameter.
Then, these functions cannot be activated anymore via the safety bus independently of the
transmitted control data.
Parameter
Information
Lenze setting
S bus: Configuration
No safety bus
S bus: Filter control data (bit-coded):
Bit 0 STO
Passing through
Bit 1 SS1
Passing through
Bit 9 ES
Passing through
Bit 11 OMS
Passing through
Bit 16 PS_AIS
Passing through
Bit 17 PS_AIE
Passing through
Bit 23 SSE
Passing through
Unlisted bits are reserved for future extensions!
