SimpleServo 500/600/i1000 User Manual Rev 3.4
TABLE 10 TB507 PIN ASSIGNMENTS
Pin
number Function Aux function Pin
number Function Aux function
1 Input A1 Left limit 14 Output 1 C
2 Input A2 Right limit 15 Output 1 E
3 Input A3 Enable 16 Output 2 C
4 Input A4 17 Output 2 E
5 Common for A
section
18 Output 3 C
6 Input B1 19 Output 3 E
7 Input B2 20 Output 4 C
8 Input B3 21 Output 4 E
9 Input B4 22 Output 5 C Ready C
10 Common for B
section
23 Output 5 E Ready E
11 Common for C
section
24 Input C4
12 Input C2 ME B 25 Input C3 Registration
13 Input C1 ME A
33
