SimpleServo 500/600/i1000 User Manual Rev 3.4
5.1.7 TB506 - Encoder repeat and analog input connections (SSi1000 drives)
TB506 is a 25-pin DB connector that includes buffered motor encoder repeat and analog input
connections.
TABLE 9 TB506 PIN ASSIGNMENTS
"D"-Sub Pin # Name Function 3
1 EA+ Encoder Channel A
2 EA- Encoder Channel A Not 4
3 EB+ Encoder Channel B
4 EB- Encoder Channel B Not
5 EZ+ Encoder Channel Z
6 EZ- Encoder Channel Z Not
7 GND Drive Common
8 SHLD Shield
9 SPARE
10 SPARE
11 SPARE
12 SPARE
13 SPARE
14 SPARE
15 SPARE
16 SPARE
17 SPARE
18 SPARE
19 SPARE
20 SPARE
21 SPARE
22 GND Logic Common
23 IN+ Positive (+) of Analog signal input
24 IN - Negative (-) of Analog signal input
25 Analog Ground Reference Signal Ground/Analog Shield
27
