SimpleServo 500/600/i1000 User Manual Rev 3.4

5.1.5

TB505 - Serial Communications Port


TB505 is a 9-pin D-sub connector that is used to communicate with a host computer via standard RS232
interface. This port is present on all SimpleServo drives. All levels must be RS-232C compliant.


TB505 Pin Assignments (all models)

"D"-Sub Pin #

Name

Function

1 Reserved

2 TX

RS232

TX

3 RX

RS232

RX

4 Reserved

5 GND

Common

6 Reserved

7 Reserved

8 Reserved

9 Reserved



WARNING!
Do not make any connection to Reserved pins!

Note

If you purchase serial cables from a third party, you must use a pass-through cable, not Null-
Modem (not crossover).

25
