Introduction
1.4 Part Number Designation
The table herein describes the part number designation for the PositionServo drive. The available filter and
communication options are detailed in separate tables.
1.4.1 Drive Part Number
E94 P 020 S 1 N E M
Electrical Products in the 94x Series
P = PositionServo Model 940 with Encoder Feedback
R = PositionServo Model 941 with Resolver Feedback
Drive Rating in Amps:
020 = 2 Amps 090 = 9 Amps
040 = 4 Amps 100 = 10 Amps
060 = 6 Amps 120 = 12 Amps
080 = 8 Amps 180 = 18 Amps
Input Phase:
S = Single Phase Input only
Y = Single or Three Phase Input
T = Three Phase Input only
Input Voltage:
1 = 120 VAC Doubler (120V, 1~ in/ 240V, 3~ out)
2 = 200/240 VAC
4 = 400/480 VAC
Line Filter:
N = No Line Filter*
F = Integrated Line Filter
Secondary Feedback:
E = Incremental Encoder
R = Standard Resolver
Safety Option:
M = MotionView OnBoard, no ISO 13849-1 safety compliance
S = MotionView OnBoard, with ISO 13849-1 safety compliance
* For 3-phase EMC installation, model 940 EMC footprint/side mount filters are required.
1.4.2 Filter Part Number
E94Z F 4 T 4 A1
Electrical Option in the 94x Series
F = EMC Filter
Filter Current Rating in Amps:
04 = 4.4 Amps 12 = 12 Amps
07 = 6.9 Amps 15 = 15 Amps
10 = 10 Amps 24 = 24 Amps
Input Phase:
S = Single Phase
T = Three Phase
Max Voltage:
2 = 240 VAC
4 = 400/480 VAC
Degree of Filtering/Variation
A1 = Industrial/1st Variation
A2 = Industrial/2nd Variation
