Lenze−Codestellen und CANopen−Objekte 8
l
46 EDSMF2181IB EN 3.0
How to read the code table
Sample of a code table
Code Name Index:
Subcode Lenze Values Access Data type
¨þ RSP ¨þ PS transfer ¨þ CANopen:
Meaning
Headers Meaning
Code Number of the parameter Cxxxxx. Name: (Lenze) "code"
Name Name of the parameter (display text in the »Engineer« and in the keypad)
Index Information on addressing the code in hexadecimal and decimal notation (decimal value in
brackets)
Leading
columns Meaning
Subcode Number of the subcode
Lenze Lenze setting ("default setting) of the code
g
Display code
The configuration of the code is not possible.
Values minimum value [smallest increment/unit] maximum value
For a display code, the displayed values are given.
Access ro: The parameter can only be read (display code).
rw: The parameter can be written.
Data type l FIX32 32 bit value with sign; decimal with 4 decimal positions
l S8 8 bit value with sign
l S16 16 bit value with sign
l S32 32 bit value with sign
l U8 8 bit value without sign
l U16 16 bit value without sign
l U32 32 bit value without sign
l VS Visible string, string with given length
Footer Meaning
RSP The parameter can only be changed when the controller is inhibited (CINH) ( þ) / not possible
( ¨).
PS transfer When the "Download parameter set" command is executed, the parameter is transferred to
the inverter (
þ) / not transferred (¨).
CANopen The reference to the corresponding CANopen object (according to CANopen specification
DS301V402) is given (
þ) / not given (¨).
