E84AYCIB communication manual (INTERBUS)
Parameter reference
Table of attributes
Table of attributes
Code Name Index Data Access
dec hex DS DA DT Factor R W CINH
C13850 All words to master 10725 29E5 A 16 UNSIGNED_16 1 ;
C13851 All words from master 10724 29E4 A 16 UNSIGNED_16 1 ;
C13852 All words to standard device 10723 29E3 A 16 UNSIGNED_16 1 ;
C13853 All words from standard device 10722 29E2 A 16 UNSIGNED_16 1 ;
C13860 Active settings 10715 29DB A 2 UNSIGNED_8 1 ;
C13861 Bus status 10714 29DA E 1 BITFIELD_16 ;
C13862 Counter 10713 29D9 A 4 UNSIGNED_16 1 ;
C13863 Active baud rate 10712 29D8 E 1 UNSIGNED_8 1 ;
C13880 Reaction on communication failure 10695 29C7 A 1 UNSIGNED_8 1 ; ;
C13881 Monitoring time for Interbus
communication failure
10694 29C6 E 1 UNSIGNED_16 1 ; ;
C13885 Delete process data 10690 29C2 E 1 UNSIGNED_8 1 ; ;
C13892 PCP - length 10683 29BB E 1 UNSIGNED_8 1 ; ;
C13893 Process data length 10682 29BA E 1 UNSIGNED_8 1 ; ;
C13894 Baud rate 10681 29B9 E 1 UNSIGNED_8 1 ; ;
C13900 Firmware product type 10675 29B3 E 1 VISIBLE_STRING ;
C13901 Firmware compilation date 10674 29B2 E 1 VISIBLE_STRING ;
C13902 Firmware version 10673 29B1 E 1 VISIBLE_STRING ;
C13920 Display DIP switch setting 10655 299F E 1 BITFIELD_8 ;
