background image

EDS84AYCIB EN 4.0 - 11/2010

L

69

E84AYCIB communication manual (INTERBUS)

Parameter reference

Parameters of the communication module

C13920

Parameter | Name:

C13920 | Display DIP switch setting

Data type: BITFIELD_8

Index: 10655

d

= 299F

h

Display of the current DIP switch position

• The set PCP data length is displayed in

C13860/1

.

• The set process data length is displayed in

C13860/2

.

• The set baud rate is displayed in

C13863

.

Possible settings through DIP switch ( 34)

Value is bit coded:

Information

Bit 0 DIP 8

Baud rate

Bit 1 DIP 7

No function

Bit 2 DIP 6

Number of parameter data words (PCP)

Bit 3 DIP 5
Bit 4 DIP 4

Number of process data words (PD)

Bit 5 DIP 3
Bit 6 DIP 2
Bit 7 DIP 1

;

Read access … Write access … CINH … PLC-STOP … No transfer … PDO_MAP_RX … PDO_MAP_TX … COM … MOT
