Lenze E84AYCIB - Manual (Page 65)

EDS84AYCIB EN 4.0 - 11/2010
L
65
E84AYCIB communication manual (INTERBUS)
Parameter reference
Parameters of the communication module
C13861
C13862
C13863
Parameter | Name:
C13861 | Bus status
Data type: BITFIELD_16
Index: 10714
d
= 29DA
h
Display of the current bus status
Querying the current bus status ( 57)
Meaning of the resulting hexadecimal values:
• 0xyyy0 = IBS-INIT
• 0xyyy1 = IBS-ACTIVE
• 0xyyy2 = IBS-READY
Value is bit coded:
Information
Bit 0 Bit 0
... ...
Bit 15 Bit 15
; Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13862 | Counter
Data type: UNSIGNED_16
Index: 10713
d
= 29D9
h
Counter for cycles and INTERBUS resets
Display area
(min. value | unit | max. value)
0 65535
Subcodes Information
C13862/1 Data cycles per second
C13862/2 Total data cycles
C13862/3 Number of INTERBUS resets
C13862/4 Number of ID cycles
; Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13863 | Active baud rate
Data type: UNSIGNED_8
Index: 10712
d
= 29D8
h
Display of the set baud rate
Selection list
(read only)
0 500 kbps
1 2.00 Mbps
; Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
