Leica SmartTouch™ Manual 80
Saving Scenarios
The Leica SmartTouch™ can store up to
5 scenarios and reproduce them later at
the touch of a button. These include the focus,
the position of the stage, fluorescence filter and
more.
If the iris and zoom are encoded, but not
automated, when calling up a scenario,
you are prompted to set the memory position
manually. For this purpose, the value of the
memory position and the current position are
displayed on the touchscreen.
Saving a scenario
1. Adjust the zoom, position of the stage,
filter wheel etc. to the positions you want
to save.
2. Touch the "Config" tab.
3. Touch the symbol for assigning the memory
locations.
4. Press approx. 3 seconds on the memory
location you want to assign the current
scenario to.
The color-coding of a key indicates
whether a memory location has already
been assigned a scenario:
1. Available memory location
2. Assigned memory location
3. Assigned, active memory location
1 2 3
