Leica SmartTouch™ Manual 19
The "Main" view allows you to see at a
glance which components can be cont-
rolled via the Leica SmartTouch™. The current
values and positions of connected instruments
are also displayed. These include, for example,
the aperture of the iris diaphragm, the posi-
tion of the motorized mechanical stage, the
currently used filters and more.
In the Main view screen, settings cannot
be modified. However, the stored confi-
gurations can still be called up (see page 63).
Calling up the Main view
1. Touch the "Main" tab to display the current
values.
2. Touch the "Focus/Zoom", "Stage" or "Light"
tabs to modify the settings for the respec-
tive instruments.
Calling up a stored configuration
1. Touch the desired hardware key to call up a
different configuration.
Calling up the Main view
