Leica SmartTouch™ Manual 78
Commands List: Toggle Button (cont'd)
Name Function
Toggle TL/FL Switches between the transmitted light shutter and the fluorescence shutter – or vice versa.
FL shutter Opens and closes the shutter of the fluorescence illuminator
Filter left Rotates the fluorescence filter wheel one position to the left
Filter right Rotates the fluorescence filter wheel one position to the right
Takes a photograph using the connected Leica digital camera.
(Leica Application Suite must be loaded for this purpose.)
Video
Starts recording a film sequence using the connected Leica digital camera. (For this purpose, the Leica Application
Suite must be loaded and the optional "Movie" expansion module must have been added.) To stop, press the button
a second time.
Memory + Switches to the next assigned memory position
Memory - Switches to the previous assigned memory position
Toggle Switches between the two command levels of the rotary actuator
