Leica SmartTouch™ Manual 52
Depending on the selected light source,
the lower area of the display changes
accordingly.
Only those light sources that are actually
connected are displayed.
Selecting the light source
1. Touch the "Light" tab.
2. Touch the desired light source in the upper
area.
Symbols for light sources
Selecting the light source
1. Fluorescence illumination
2. Transmitted Light Base RCI
3. LED5000 MCI
4. LED5000 RL-80/48
5. LED5000 CXI
6. LED3000 RL
7. LED3000 NVI
8. LED5000 HDI
1 2 3 4
5 6 7 8
