Leica SmartTouch™ Manual 56
Control of the Leica LED5000 3000 Ring Illuminator
Using the Leica SmartTouch™, you can
control both the brightness and various
illumination scenarios for the Leica LED3000 RL
("Ring Light").
Adjusting the illumination
1. Touch the "Light" tab.
2. In the upper area, touch the symbol for the
Leica LED3000 RL.
3. Switch on the illuminator.
4. Touch the lamp symbols to adjust the inten-
sity of the light.
5. Touch one of the symbols for the light
scenarios to adjust the lighting to your
needs.
You cannot modify the default illumina-
tion scenarios.
