Leica SmartTouch™ Manual 66
Zoom
Zoom in Enlarges the view (zoom)
Zoom out Reduces the view (zoom)
Ratchet + Switches to the next ratchet stop position
Ratchet - Switches to the previous ratchet stop position
Open iris Opens the iris (= smaller depth of field, but more light)
Close iris Closes the iris (= greater depth of field, but less light)
Focus
Focus up Moves the focusing column upwards in larger increments
Focus down Moves the focusing column downwards in larger increments
Focus fast Switches the focusing speed to "Fast"
Focus autom. Switches the focusing speed to "Auto"
Focus slow Switches the focusing speed to "Slow"
Focus abs./rel. Changes the focus display between "absolute" and "relative"
Focus ref. Sets the current focus position to the value "0"
Fine focus
Fine focus up Moves the focusing column upwards in small increments
Fine focus down Moves the focusing column downwards in small increments
Memory Key Commands List
