Leica SmartTouch™ Manual 42
Iris diaphragm control
1. Use the iris diaphragm control keys to open
and close the iris diaphragm. The effects
on the depth of field are shown on the
Leica SmartTouch™ under "DOF" (Depth Of
Field).
Zoom Settings (cont'd.)
2. Touch the circle key to use the area covered
by the optional graticule (Art. No. 10450054)
for the measurement. Use this measuring
method only if your microscope is equipped
with this graticule in the eyepiece.
The effects of the selected measur-
ing method are shown directly in the
display.
