Memory key commands list (cont'd) – Leica Biosystems SmartTouch User Manual
Page 69
Leica SmartTouch™
Manual
69
Memory Key Commands List (cont'd)
Transmitted light
TL shutter
Switches the illuminator of the transmitted light base on and off
Toggle TL/FL
Changes the status of the transmitted light and fluorescence shutter
TL color temp +
Increases the lamp voltage
TL color temp -
Decreases the lamp voltage
TL brightness +
Opens the CCIC diaphragm
TL brightness -
Closes the CCIC diaphragm
Fluorescence
Filter 1
…
Filter 4
(Fluorescence) Rotates the filter wheel directly into filter position 1 to 4
FL shutter
Opens and closes the shutter of the fluorescence illuminator
FIM +
Increases the brightness by opening the FIM (Fluorescence Intensity Manager)
FIM -
Reduces the brightness by closing the FIM
Filter left
Replaces the current filter with the one to the left of it
Filter right
Replaces the current filter with the one to the right of it
