Leica SmartTouch™ Manual 49
You can toggle the coordinate system
between the Cartesian coordinate system
and the polar view.
Changing the coordinate system
1. Touch the "Stage" tab.
2. In the "Stage" area, touch the desired coor-
dinate system:
Ϙ
Cartesian coordinates (left symbol): Shows
the distance between the bottom left
corner and the current position based on
the X/Y-axes.
Ϙ
Polar coordinates (right symbol): Displays
the distance based on the radius and
angle.
The display as polar coordinates can also
be used for simple distance measure-
ments.
Changing the Coordinate System
