Leica SmartTouch™ Manual 72
Information about the Double Rotary Actuator
The double rotary actuator consists
of two knobs, each of which can be
assigned two different functions. Thus a total
of four functions are available, which can be
assigned individually.
The toggle button is located at the top
end of the double rotary actuator. It is
used to toggle between the two assignments.
If the rotary actuators are not doubly assigned,
the toggle button can be assigned a function.
Toggle button
Top rotary actuator
Bottom rotary actuator
Double rotary actua-
tor
