Kinze 3600 Lift and Rotate Planter (70 CM) Rev. 6/14 - Manual (Page 99)

ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
1 GA13719
G10168
G10045
G10844
G10228
G10102 1
2
1
1
2
2 See “Row Marker Spindle/Hub/Blade” on page P99
Machine Bushing, ½", 7 Gauge
Hex Head Cap Screw, ½"-13 x 4½"
Carriage Bolt, ½"-13 x 3½"
Lock Washer, ½"
Hex Nut, ½"-13
2 GD0453-02 1 Extension Tube, 40"
3 GA13114
GD2721
G10228
G10102
G10643 1
1
2
2
-
Arm, Third Stage
U-Bolt, 2" x 2" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
Grease Fitting, 45°, ¼"-28
4 GD18889
G10460
G10345 1
2
2 Pin, 1" x 9¼"
Cotter Pin, ¼" x 2"
Machine Bushing, 1", 14 Gauge
5 GA9145
G10004
G11387
G10108 1
2
2
2 Molded Stop, 6¼" Long
Hex Head Cap Screw, ⅜"-16 x 1¼"
Flat Washer, ⅜" SAE
Lock Nut, ⅜" -16
6 GD18540
G10004
G10108 1
2
2 Lock-up Chain Bracket
Hex Head Cap Screw, ⅜"-16 x 1¼"
Lock Nut, ⅜"-16
7 GA13764
G11391
G10006
GB0218
G10107 1
2
2
2
2 Linkage
Flat Washer, ⅝" SAE
Hex Head Cap Screw, ⅝"-11 x 2¼"
Bushing, 21∕32" I.D. x ⅞" O.D. x 19∕32" Long
Lock Nut, ⅝"-11
8 GD25189
GD3180-34
GD10538-07
G10039
G10111 1
-
-
-
-
Marker Link
Sleeve, ⅞" O.D. x ⅝" I.D. x 2"
Sleeve, ¾" O.D. x ½" I.D. x .3⁄5"
Hex Head Cap Screw, ½"-13 x 1¾"
Lock Nut, ½"-13
9 G10036
G11391
G10107 1
2
1 Hex Head Cap Screw, ⅝"-11 x 4"
Flat Washer, ⅝" SAE
Lock Nut, ⅝"-11
10 GA18283 1 Marker Link, 103¼"
11 G10033
GD19661-01
GD16418-02
G10111 1
1
2
1 Hex Head Cap Screw, ½"-13 x 3½"
Sleeve, ¾" O.D. x 51∕100 I.D. x 2"
Sleeve, 1⅛" O.D. x 13∕16" I.D. x 11∕25"
Lock Nut, ½"-13
12 GD18815
G10159
G10460 1
2
2 Pin, 1¼" x 8.38"
Washer, 1⅞"
Cotter Pin, ¼" x 2"
13 GA14632
G6801-08
GR1037
G6400-08-04
GR1465 1
1
-
1
-
See “Row Marker Cylinder” on page P101
Elbow W/O-Ring, 90°, ¾"-16 Male JIC To O-Ring
O-Ring
Connector W/O-Ring, ¾"-16 Male JIC To 7∕16"-20 O-Ring
O-Ring
14 GD26024
G306-08
G2701-08
G10107 1
2
2
2 Bulkhead Mount
Lock Nut, ¾"-16
Bulkhead Elbow, 90°, ¾"-16 Male JIC
Lock Nut, ⅝"-11
15 GD13359 1 Plate, 7" x 7"
16 GD11791 4 Shim, 2½" x 8¼", 16 Gauge, 16 Row
Row Marker Assembly
Continued on the next page.
