Dry Fertilizer Drive
ITEM PART NO. QTY. DESCRIPTION
1 G3400-01 4 Flangette
2 GA5109 2 Sprocket, 24 Tooth
3 GA17975 1 Idler Arm
4 GA7154 1 Sprocket W/Bearing, 18 Tooth
5 GD26479 1 Idler Pivot Nut
6 G2100-03 2 Bearing, ⅞" Hex Bore, Spherical
7 GA18382 1 Dry Fertilizer Mount
8 GD5886 1 Coupler, 1¾"
9 GD26880
GD26879 1
-
Dry Fertilizer Hex Shaft, 4¾"
Dry Fertilizer Hex Shaft, 8¼"
10 GD26560 1 Dry Fertilizer Bracket
11 GD26565 1 Dry Fertilizer Hex Shaft
12 G11389 1 Flat Washer, ½" Plated SAE
13 G10039 1 Hex Head Cap Screw, ½"-13 x 1¾"
14 GD5857 1 Spring
15 G10602 5 Spring Pin, ¼" x 1½"
16 G10111 2 Lock Nut, ½"-13
17 G11390 4 Flat Washer, 9⁄16" SAE
18 G10017 2 Hex Head Cap Screw, ½"-13 x 1½"
19 G10923 6 Flange Nut, 5⁄16"-18, No Serration
20 G10312 6 Carriage Bolt, 5⁄16"-18 x ¾"
21 G10213 1 Machine Bushing, ⅝" (.030" Thick)
22 G11391 1 Flat Washer, ⅝" SAE
23 GD10161 2 Spacer, ⅜"
24 GA11331 2 Hex Lock Clamp Assembly
25 G11555 1 Hex Socket Head Shoulder Screw, ⅜"-16 x ½"
26 G10870 1 Clevis Pin, ⅜" x 1"
27 G10860 1 Retaining Ring, ⅜"
28 G3310-62
GR0912 1
-
Chain No. 40, 62 Pitch Including Connector Link
Connector Link, No. 40
29 GA18614
GA18613 1
-
R.H. Dry Fertilizer Bracket
L.H. Dry Fertilizer Bracket
30 GA5116 2 Bearing, ⅞" Hex Bore, Cylindrical
31 GR0911 1 Offset Link, No. 40
