Ground Drive Wheel
ITEM
PART NO.
QTY.
(Per Assy.)
DESCRIPTION
1
GA14349
1
Wheel Module
2
GD20461
1
Pin, 1¼" x 13"
3
G11400
2
Retaining Ring, 1¼"
4
GD5841
G11396
G10460
1
2
2
Pin, 1¼" x 5⅝"
Flat Washer, 1¼" SAE
Cotter Pin, ¼" x 2"
5
GD20458
1
R.H. Slotted Scrapper
6
G10636
G10071
2
2
Carriage Bolt, ½"-13 x 1½"
Serrated Flange Nut, ½"-13
7
GD20458
1
Slotted Scrapper
8
G10026
G10231
3
2
Hex Head Cap Screw, ¾"-10 x 2"
Lock Washer, ¾"
9
G11314
1
Serrated Flange Nut, ¾"-10
10
G11081
2
Hex Jam Nut, 1½"-12, Grade 2
11
GA0895
2
Bearing
12
GA2148
GR0434
1
2
Hub W/Cups, 6 Bolt
Cup
13
GA4376
1
Spindle W/Round External Retaining Ring, 10"
14
GD11490
1
Round External Retaining Ring
15
GD13401
GA7434
1
1
Tire, 7.50" x 20", 8 Ply, Tubeless W/O Center Rib (Specify Brand*)
Valve Stem
16
GA14413
1
Rim, 5.5" x 20"
17
GR0270
6
Lug Bolt, 9∕16"-18
A
GA14412
-
Tire And Rim Assembly (Specify Brand*) (Items 15 and 16)
B
GA4377
-
Hub And Spindle Assembly (Items 10-13)
*
Specific brand requests will be supplied only as available from current Kinze
Repair Parts stock. If a specific brand
requested is not in stock, the brand available will be supplied.
