Kinze 3600 Lift and Rotate Planter (70 CM) Rev. 6/14 - Manual (Page 87)

Seed Rate Transmission and Row Unit Drill Shafts
ITEM PART NO. QTY.
(Per Side)
DESCRIPTION
17 G3310-80
GR0912 1
-
Chain, No. 40, 80 Pitch Including Connector Link
Connector Link, No. 40
18 GA7336
GD7426
G10047
GD1026
G11387
G10229 1
-
-
-
-
-
Idler W/Bolt-On Sprockets
Sprocket, 12 Tooth
Hex Head Cap Screw, ⅜"-16 x 1¾"
Sleeve, 13∕16" Long
Flat Washer, ⅜" SAE
Lock Washer, ⅜"
19 GD7612 1 Shaft, ⅞" x 13½"
20 G10303
G10620 -
- Carriage Bolt, 5∕16"-18 x 1"
Hex Nut, 5∕16"-18
21 GA5548 1 Special Bearing
22 G3400-01 - Flangette
23 G2100-03 - Bearing, ⅞" Hex Bore, Spherical
24 GA8092 1 Clutch Sprocket Assembly, 19 tooth ( See “Interplant Push Row Unit Drive” on page P49 )
25 GD11045 - Lock Clamp
26 GD0914-126.75 2 Hex Shaft, ⅞" x 126¾" (No Holes), Wing
27 GA2180 - Hanger Bearing, ⅞" Hex Bore
28 G10130
G10923 -
- Square Head Machine Bolt, 5∕16"-18 x 1¾"
Flange Nut, 5∕16"-18, No Serration
29 G10233 - Machine Bushing, 1", 10 Gauge
30 GA18276
GR1557
GR2148
GR1294
GR2151 -
-
-
-
- U-Joint W/Grease Fitting, Female, 10¼" Long, 16 Row
Grease Fitting, 45°, Metric
Inboard Yoke And Outer Profile
Cross And Bearing Kit
Yoke, ⅞" Hex
31 GA18275
GR1557
GR2147
GR1295
GR1301
GR1294
GR2151 -
-
-
-
-
-
- U-Joint W/Grease Fitting, Male, 12¼" Long
Grease Fitting, 45°, Metric
Inner Profile
Inboard Yoke
Spring Pin, 8 mm x 50 mm
Cross And Bearing Kit
Yoke, ⅞" Hex
32 GD0914-71
GD0914-60 1
-
Hex Shaft, ⅞" x 71" (No Holes), R.H. Main Frame
Hex Shaft, ⅞" x 60" (No Holes), L.H. Main Frame
33 G10004
G10229
G10101 2
2
-
Hex Head Cap Screw, ⅜"-16 x 1¼"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
34 G11100
G10227
G11453 1
1
1 Hex Socket Button Head Cap Screw, ¼"-20 x ½", Grade 8
Lock Washer, ¼"
Fender Washer, ¼"
35 G10235 1 Machine Bushing, ⅞", 14 Gauge
A G1K269 - Lock Clamp Kit (Items 25 And 28)
B G1K381
G1K380 -
- Wrap Spring Wrench Replacement Kit, Gray Collar, L.H. (Items 34-43) (Shown)
Wrap Spring Wrench Replacement Kit, Blue Collar, R.H. (Items 34-43)
Model 3600 M0249-02
12/12 P84
