Kinze 3600 Lift and Rotate Planter (70 CM) Rev. 6/14 - Manual (Page 55)

Manifolds and Mounts
ITEM PART NO. QTY. DESCRIPTION
1 D15850 2 MANIFOLD, OPEN ONE END
2 D15856-04 8 PIPE, 6" X 6" PVC LW DUCT BLACK
3 D15854 14 CLAMP, MANIFOLD
4 D15799 12 MANIFOLD, OPEN BOTH ENDS
5 A18394 1 WELD MANIFOLD
6 D15856-03 2 PIPE, 6" X 11" PVC LW DUCT BLACK
39
35
36
37
38
36
38
36
36
38
38
38
36
38
39
38
36 12
41 41 41 41 40 40
12
38 38
36
38
24
38
40
38
36
35
ITEM PART NO. QTY. DESCRIPTION
1 --- 1 See “Vacuum System” on page P55
2 GA14382 1 Fan Mount
3 GA14386 1 EdgeVac Fan Mount
4 G10164
G11387
G11091 1
1
1 Hex Head Cap Screw, ⅜"-16 x 2¼", Full Thread
Flat Washer, ⅜" SAE
Serrated Flange Nut, ⅜"-16
5 GA14378
G10001
G11091 1
2
2 EdgeVac Fan Strut
Hex Head Cap Screw, ⅜"-16 x 1"
Serrated Flange Nut, ⅜"-16
6 GA11068
G10809
G11091
1
2
2
See “Vacuum Fan Motor Valve Block Assembly (Located Below Vacuum Fan Motor
Assembly)” on page P122
Hex Head Cap Screw, ⅜"-16 x 3¼"
Serrated Flange Nut, ⅜"-16
7 GD20590
G10034
G10229 1
2
2 EdgeVac Hydraulic Block Mount
Hex Head Cap Screw, ⅜"-16 x ½"
Lock Washer, ⅜"
8 GD26707-02 - Manifold Rail, 108"
9 G6500-10 1 Swivel Elbow, 90°, ⅞"-14 Male JIC To Female
10 G6500-12
G6502-12 1
1 Swivel Elbow, 90°, 11∕16"-12 Male JIC To Female
Swivel Elbow, 45°, 11∕16"-12 Male JIC To Female
11 G6500-06 1 Swivel Elbow, 90°, 9∕16"-18 Male JIC To Female
12 GD16317-02 2 Hose, 7" x 30"
13 G10055
G10107 2
2 Hex Head Cap Screw, ⅝"-11 x 1¼"
Lock Nut, ⅝"-11
14 GA14383 1 Fan Strut Mount
15 GA14384
G10156 1
1 Strut Mount, R.H.
Hex Head Cap Screw, ¾"-10 x 1¼"
16 GA14385
G10156 1
1 Strut Mount, L.H.
Hex Head Cap Screw, ¾"-10 x 1¼"
17 GD20534
G10462 1
2 Lower Strut Pin
Cotter Pin, 3∕16" x 2"
18 GD20518
G10462 1
2 Upper Strut Pin
Cotter Pin, 3∕16" x 2"
19 GD14627 Coupler, 2"
20 G11147 Cap, 2"
21 G10676 Hose Clamp, No. 36, Stainless Steel
22 GD14626 Elbow, 90°, 2"
Continued on the next page.
Model 3600 M0249-02
12/12 P52
