Kinze 3600 Lift and Rotate Planter (70 CM) Rev. 6/14 - Manual (Page 83)

Drive Shaft(s)
ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
1 GD10375 4 Wheel Tower
2 GD10298 2 Cover
3 GD6895 2 Shield
4 GD9969 1 Bracket
5 GD5789 2 Hinge, Female
6 --- 2 See “Contact Wheel” on page P81
7 G10235 14 Machine Bushing, ⅞", 14 Gauge (.0747")
8 GD5857 4 Spring
9 GD26498 1 Hex Shaft, ⅞" x 28.44"
10 GD10401 1 Double Idler Bar
11 GD1026 2 Sleeve, 13⁄16" Long
12 GD7426 2 Sprocket, 12 Tooth
13 G10229 2 Lock Washer, ⅜"
14 G11387 2 Flat Washer, ⅜" SAE
15 G10047 2 Hex Head Cap Screw, ⅜"-16 x 1¾"
16 G11387 1 Flat Washer, ⅜" SAE
17 GD14431
G11078 1
1 Wrap Spring Wrench Handle
Vinyl Cap
18 GD14432 1 Wrap Spring Wrench Sleeve
19 G11075 2 External Inverted Snap Ring, ⅞"
20 G10496 2 External Inverted Snap Ring, 1½"
21 GD19344
GD19343 1
-
Release Collar, Silver, L.H. (Shown)
Release Collar, Blue, R.H.
22 GD14414
GD14413 1
-
Torsion Spring, R.H. (Used On L.H. Wrap Spring Wrench) (Shown)
Torsion Spring, L.H. (Used On R.H. Wrap Spring Wrench)
23 GD14426 1 Tightener Shaft, 3⅜"
24 G10064 14 Hex Head Cap Screw, ¼"-20 x 1"
25 G10621 14 Serrated Flange Nut, ¼"-20
26 G11100 1 Hex Socket Button Head Cap Screw, ¼"-20 x ½", Grade 8
27 GD2199 1 SMV Sign
28 --- - See “Inner Module Drive” on page P85
29 GD5212 1 Coupler, 1¾", 16 Row 30" Only
30 --- - See “Point Row Clutch” on page P87
31 G10233
G10345 2
2 Machine Bushing, 1", 10 Gauge
Machine Bushing, 1", 14 Gauge
A GA3552 - Tire And Rim Assembly (Specify Brand*)
B GA5164
GA9843 -
- Ratchet/Sprocket Assembly, L.H. Side Of Planter
Ratchet/Sprocket Assembly, R.H. Side Of Planter
C G1K324 - Contact Wheel Arm Replacement Kit
D G1K381
G1K380 -
- Wrap Spring Wrench Replacement Kit, Gray Collar, L.H. (Items 42-48) (Shown)
Wrap Spring Wrench Replacement Kit, Blue Collar, R.H. (Items 42-48)
* Specific brand requests will be supplied only as available from current Kinze Repair Parts stock. If a specific brand
requested is not in stock, the brand available will be supplied. Different brand tires may have different diameters. Change
in tire brand may affect rates. Field checks are recommended after any change in contact tires.
