Kinze 3600 Lift and Rotate Planter (70 CM) Rev. 6/14 - Manual (Page 89)

Inner Module Drive
ITEM PART NO. QTY.
(Per Module)
DESCRIPTION
1 G10053 - Hex Head Cap Screw, ½"-13 x 2½"
2 G10111 - Lock Nut, ½"-13
3 --- --- ---
4 GA9558
GA9557
GA7154
G10038
GD10007
G11389
G10111 1
-
-
-
-
-
-
Idler W/Sprocket And Hardware, L.H. Side Of Planter
Idler W/Sprocket And Hardware, R.H. Side Of Planter
Sprocket W/Bearing, 18 Tooth
Hex Head Cap Screw, ½"-13 x 3"
Spacer, 1⅛" Long
Flat Washer, ½" SAE
Lock Nut, ½"-13
5 G11391 - Flat Washer, ⅝" SAE
6 G10036 - Hex Head Cap Screw, ⅝"-11 x 4"
7 G10107 - Lock Nut, ⅝"-11
8 G10503 - Hex Jam Nut, ⅝"-11, Grade 2
9 GD7889 - Bushing, 1" O.D. x 9⁄16" I.D. x 7⁄16" Long
10 GD10543 - Hex Shaft, ⅞" x 13"
11 GA5164 - Ratchet/Sprocket Assembly
12 GD5857 - Spring
13 G3400-01 - Flangette
14 G2100-03 - Bearing, ⅞" Hex Bore, Spherical
15 G10303 - Carriage Bolt, 5⁄16"-18 x 1"
16 G10620 - Serrated Flange Nut, 5⁄16"-18
17 G10233 - Machine Bushing, 1½" x 1⁄32", 10 Gauge (.1345")
18 G10602 - Spring Pin, ¼" x 1½"
19 GD26497 - Hex Shaft, ⅞" x 30"
20 G10595 - Hex Head Cap Screw, ⅜"-16 x 10"
21 GA5194 - Sprocket, 50 Tooth
22 GA7111 - Point Row Clutch Assembly, L.H.
23 GA5113 - Sprocket, 28 Tooth
24 GA7154 - Sprocket W/Bearing, 18 Tooth
25 G10168 - Machine Bushing, ½", 7 Gauge (.1793")
26 G10345 - Machine Bushing, 1", 14 Gauge (.0747")
Model 3600 M0249-02
12/12 P86
TM
