Tongue Cylinder
ITEM PART NO. QTY. DESCRIPTION
1 A13953 1 Barrel (Non-Stock Item)
2 G6400-08-04
GR1465 1
-
Connector W/O-Ring, ¾"-16 Male JIC To 7∕16"-20 O-Ring
O-Ring
3 GA8979
G10990 1
1 Hydraulic Tube Assembly, 9211∕16"
Hose Clamp, No. 52
4 G2700-08
G306-08 1
1 Bulkhead Tube Union, ¾"-16 Male JIC
Lock Nut, ¾"-16
5 GD12597
G10328
G10229 1
1
1 Bracket
Hex Head Cap Screw, ⅜"-16 x ⅝"
Lock Washer, ⅜"
6 G6408-08
GR1037 1
-
Plug W/O-Ring, ¾"-16 O-Ring
O-Ring
7 G304-C-08 1 Cap Nut, ¾"-16
8 GA8859 1 Rod Assembly
9 GD12104 1 Ring
10 *D12200 1 Wiper
11 GD11984 1 Gland
12 *D12253 1 U-Cup
13 *D12203 1 BU Ring
14 *D12202 1 O-Ring, No. 334
15 GD26483 1 Stroke Limiter
16 *D12204 1 O-Ring, No. 218
17 *D12278 1 T-Seal
18 GD11970 1 Piston
19 *D12047 1 Wear Ring
20 GD27237 1 Nylon Lock Nut, 1¼"-12, Grade 8
A GA18287 - Cylinder Complete, 3" x 73.38" (Part Number Stamped On Barrel)
B GR1519 - Seal Kit Includes: (2) O-Rings, (1) BU Ring, (1) Wear Ring, (1) Wiper, (1) U-Cup, (1)
T-Seal
* Item is part of seal kit, item can not be purchased individually.
Model 3600 M0249-02
Rev. 6/14 P110
