Wing Frame
ITEM PART NO. QTY. DESCRIPTION
1 A18295
A18294 1
-
L.H. Wing (Two Wheel Towers Per Wing) (Non-Stock Item)
R.H. Wing (Two Wheel Towers Per Wing) (Non-Stock Item)
2 ---
G11330
G10110 1
4
4 See “Electrical Components” on page P127
Hex Head Cap Screw, ¼"-20 x 1¼"
Lock Nut, ¼"-20, Grade B
3 GA9840 1 Light Bracket
4 G10033
G10111 1
-
Hex Head Cap Screw, ½"-13 x 3½"
Lock Nut, ½"-13
5 GB0309 1 Light Mount Bracket
6 G10874 1 Detent Pin, ½" x 3½" Grip
7 GD1908 1 Mounting Bracket
8 G10012
G10230
G10104 2
2
2 Hex Head Cap Screw, ⅝"-11 x 6½"
Lock Washer, ⅝"
Hex Nut, ⅝"-11
9 --- - See “Wing Lift Cylinder” on page P103
10 GD5841
G11396
G10460 1
2
2 Pin, 1¼" x 5⅝"
Flat Washer, 1¼" SAE
Cotter Pin, ¼" x 2
11 --- - See “Ground Drive Wheel” on page P77
12 --- - See “Ground Drive Wheel” on page P77
13 G6400-L-08
GR1037 1
-
Long Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
14 G6400-08
GR1037 1
-
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
15 G6500-08 1 Swivel Elbow, 90°, ¾"-16 Male JIC To Female
16 G10017
G11389
G10111 2
2
2 Hex Head Cap Screw, ½"-13 x 1½"
Flat Washer, ½" SAE
Lock Nut, ½"-13
17 GA14359 2 Cylinder Pin
18 G10001
G10229
G10101 2
2
2 Hex Head Cap Screw, ⅜"-16 x 1"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
19 GD12703 1 Push Row Unit Light Bracket
A G7698X - Push Row Unit Mounted Light Bracket Package (Items 22 And 23 On This Page And
42" Harness Extension, Item 5 On
page P127 )
