Kinze 3600 Lift and Rotate Planter (70 CM) Rev. 6/14 - Manual (Page 50)

Interplant Push Row Unit
ITEM PART NO. QTY.
(Per Row)
DESCRIPTION
35 GD18073 1 Bracket (Lift Lever)
36 GD9695 1 Wire Lock Pin, ¼" x 1¾"
37 GD18074 1 Mount
38 G11387 1 Flat Washer, ⅜" SAE
39 GA9105
G10230
G10104 -
-
- T-Bolt, ⅝"-11 x 6" (Center Rows)
Lock Washer, ⅝"
Hex Nut, ⅝"-11
40 GD17052
G10001
G10108
G11387 -
-
-
- Vacuum Plug
Hex Head Cap Screw, ⅜"-16 x 1"
Lock Nut, ⅜"-16
Flat Washer, ⅜" SAE
41 GA12677
GA18304 - Offset Hinge Mount
Offset Hinge Mount
42 G10341
G10230
G10104 -
-
- Hex Head Cap Screw, ⅝"-11 x 8"
Lock Washer, ⅝"
Hex Nut, ⅝"-11
43 GD7817-18 2 Spacer, 11⁄16" I.D. x 5 ½" Long
44 GD18136 4 Pad
45 GD18135 1 Bar
TM
M0249-02 Model 3600
P47 12/12
