Front panel – Intelix ASW-WP Installation Manual User Manual
Page 5
ASW-WP Installation Guide
Front Panel
HDMI Input status LED – Indicates power, active signal, and selected input for the HDMI input.
(p. 11)
PC Input status LED – Indicates power, active signal, and selected input for the PC Video input.
(p. 11)
HDMI Input – Video sensing HDMI input
PC Video and Audio Input – Video sensing PC Video and Audio input that converts the signal to a
digital format
HDMI Input
HDMI Input
Status LED
PC Input
Status LED
PC Video
and Audio
Input
5
