ASW-WP Installation Guide
HDBaseT Signal Characteristics
Maximum Distance
60 m
Cable Requirements
Category 6, or 6A with TIA/EIA-568B crimp pattern
(shielded cable and connectors are recommended)
Bandwidth
10.2 Gbps
Gain
0 dB – 10 dB at 100 MHz
Signal to Noise Ratio (SNR)
> 70 dB at 100 MHz over 100 m
Return Loss
< -30 dB at 5 KHz
Total Harmonic Distortion (THD)
< 0.005% at 1 KHz
Min-Max Signal Level
< 0.3 V – 1.45 Vp-p
Differential Phase Error
±10° at 135 MHz over 100 m
Chassis and Environmental
Construction
Black painted metal plate (Back Cover)
Faceplate Colors
White ABS Plastic
Dimensions
114mm x 116mm x 35mm (4.49 in. x 4.57 in. x 1.38 in.)
Shipping Weight
0.45 kg (1 lbs.)
Operating Temperature
0° to +40° C (+32° to +104° F)
Operating Humidity
20% to 90%, Non-condensing
Storage Temperature
-10° to +60° C (+14° to +140° F)
Storage Humidity
20% to 90%, Non-condensing
Power, ESD, and Regulatory
Power Supply
5vDC 2A or PoE (Power over Ethernet)
Power Consumption
10 watts
Default Automatic Standby Mode
30 minutes no signal
ESD Protection
16kV
Regulatory
CE, RoHS
Other
Warranty
2 years
Diagnostic Indicators
Front Panel: Two (2) Bicolor LED: Blue, (Purple), Amber
HDBaseT: Three (3) SMDs: Heartbeat – Blue, Link –
Yellow, HDMI – Green
Included Accessories
White Faceplate Set and Installation Manual
HDBaseT Receiver (A/V, PoE, Control)
Compatibility
DIGI-HD60C-R
HDBaseT Receiver (A/V, Control)
Compatibility
DIGI-HDE-R, FLX-BI4
HDBaseT Receiver (A/V Only)
Compatibility
DIGI-HD70-R
Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF
and electrical interference, and cable patches.
