Technical Specifications
Technical Specifications
I/O Connections
HDMI Input
One (1) HDMI Type A Receptacle (Front)
VGA Input
One (1) Female PC Video HD-15-F Connector (Front)
PC Stereo Audio
One (1) 3.5 mm TRS Receptacle (Front)
HDBaseT Port
One (1) 8P8C port (Shielded RJ45)
Power
One (1) 2 Position Euroblock Connector
EDID Dipswitches
Three (3) 2 position switches
Contact Closures
One (1) 4 position Euroblock Connector
Supported Audio and Video
HDMI Video Resolutions
SMPTE: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
VESA: Resolutions up to 1920x1200
Color Depth: 24, 30, 36, 48bit
VGA Video Resolutions
SMPTE: 480p@60hz, 576p@60hz, 720p@60hz,
1080p@60hz
VESA:
• 640x480, 800x600, 1024x768, 1280x768,
1280x800, 1280x1024, 1600x1200,
1680x1050, 1920x1200(RB) - @60hz
• 640x480, 800x600, 1024x768, 1280x1024 -
@75hz
• 640x480, 800x600, 1024x768, 1280x1024 -
@85hz
• 1024x768 - @70hz
• 640x480, 800x600 - @72hz
Maximum Video Compatibility at 60 m
Deep Color 36/30/24 Bit at 1080p (HDMI Input)
Maximum Video Compatibility at 40 m
Deep Color 48 Bit at 1080p, 3D (HDMI Input)
Video Compliance
HDMI and HDCP (Selectable)
HDMI Embedded Audio
Up to PCM 8 channel, Dolby Digital TrueHD, and DTS-
HD Master Audio
PC Embedded Audio
Analog stereo line-level (Converted to 2ch 24bit PCM
48kHz)
ARC (Audio Return Channel)
No
HEC (HDMI Ethernet Channel)
No
CEC (Consumer Electronics Control)
Yes (HDMI Pass-through Only)
Baud Rate (Wall plate control)
9600
Supported Baud Rates (Display Control)
9600, 19200, 57600, 115200
