ASW-WP Installation Guide

RS232 and TCP/IP Commands

RS232 Settings: 9600 baud, 8 Data bits, 1 Stop bit, Parity = None


=

Carriage return (Hex 0D)

=

Line Feed (Hex 0A)

=

Space (Hex 20)

*NOTE: You must turn Display Control OFF in order to gain control of the ASW-WP via RS232 –

please send the “Display Control OFF” command first! (See page 16)

System commands

Description

Command

Response

Select HDMI input

SET HDMI

SET HDMI!

Select VGA input

SET VGA

SET VGA!

Get selected input

GET IN

GET IN!

Get HDMI video status

GET HDMI

HDMI 1!
This response indicates video

present on HDMI input
HDMI 0!

This response indicates NO video

present on HDMI input

Get VGA video status

GET VGA

VGA 1!
This response indicates video

present on VGA input
VGA 0!
This response indicates NO video

present on VGA input

Turn auto-switching on

AUTO ON

AUTO ON!

Turn auto-switching off

AUTO OFF

AUTO OFF!

Enter low-power mode (will disable

RS232 communications until

physical action wakes up ASW-WP)

STANDBY

STANDBY!

Reset microprocessor

RST

No response – ASW-WP will power

cycle

HDCP Compliance ON

HDCP ON

HDCP ON!

HDCP Compliance OFF

HDCP OFF

HDCP OFF!

Get HDCP Compliance status

GET HDCP

HDCP ON!
Or
HDCP OFF!
