RQCM – RESEARCH QUARTZ CRYSTAL MICROBALANCE

GLOSSARY

11-1

11 GLOSSARY

Conductance

The ability to conduct. Conductance is the inverse of resistance.

Conductance = 1/Resistance, or Resistance = 1/Conductance.

The units of resistance are Ohms [Ω = V/A] and the units of conductance are Siemens

(S = A/V].

CPVC

Abbreviation for chlorinated polyvinyl chloride, a resin patented by Goodrich, it has

excellent mechanical strength and stability over temperature, and offers good

resistance over a selective range of chemicals.

Crystal Bandwidth

Refers to the crystal’s frequency response range, bounced by the frequency values

cross at half the resonance frequency’s magnitude. It is defined as f

o

/Q (resonance

frequency/crystal Q).

Crystal Holder

A device that houses the crystal and provides connections to the crystal’s electrodes

via a coaxial connector.

Crystal Q

A figure of merit used in describing the "sharpness" of the crystal response. (It is also

called crystal quality factor.)

Kynar®

Pennwalt’s registered trademark of Polyvinilidene Fluoride (PVDF), a homopolymer

of 1,1-di-fluoro-ethene, is a tough thermoplastic that offers unique properties

including: high chemical inertness, low permeability to gases and liquids, resistance to

radiation and excellent mechanical strength and toughness. Visit

www.atofinachemicals.com

for more detailed information.

Picofarad

10

-12

farads. A common unit of capacitance (abbreviated as pfd). By definition, 1

farad will store a 1 Coulomb charge when connected across a 1 volt potential.

PLO

Phase Lock Oscillator. A type of electronic circuit in which the frequency and the

phase of the Voltage Controlled Oscillator (VCO) is locked to the frequency and the

phase of a reference signal (in our case the signal from the sensing crystal).

Quadrature (current)

Refers to the imaginary component of the current through the shunt capacitance, C

S

.

RQCM

INFICON QCM instrument’s model name, which stands for Research Quartz Crystal

Microbalance.

RTD

Resistance Temperature Detector. A device that changes its resistance as a function of

temperature.

Shunt Capacitance

Effective capacitance due to the electrodes on the crystal. This is the "unwanted"

capacitance we try to cancel out (along with the capacitance in the cable and the holder

of course) while adjusting the Fine & Coarse capacitance cancellation on the Crystal

Measurement Channel(s) on the RQCM.

Teflon®

DuPont Company’s registered trademark of Perfluoroalkoxy Fluorocarbon Resin, a

class of Teflon that offers excellent inertness to aqueous acid and aqueous alkaline,

superior resistance over a wide range of pH. Visit

www.dupont-dow.com

for more

information.

VCO

Voltage Controlled Oscillator. An oscillator circuit designed so that the output

frequency can be controlled by applying a voltage to its control or tuning port.
