RQCM – RESEARCH QUARTZ CRYSTAL MICROBALANCE

CRYSTALS, HOLDERS AND FLOW CELL

4-1

4 CRYSTALS, HOLDERS AND FLOW CELL

An essential part of the RQCM system is the sensing crystal. Careful handling of both the crystal

and the crystal holder must be observed to ensure proper and reproducible measurements.

Furthermore, the sensing crystal, the crystal holder and the connecting cable must be orientated

and connected correctly in order for the RQCM to work properly. This is especially true if you

design your own crystal or holder.
If you have purchased a INFICON crystal, holder and cable, the installation is simple. Follow the

instructions below.
If you plan to build your own crystal or holder or cable, see Section 4.3.2.

4.1 1 INCH DIAMETER CRYSTALS

IINFICON

pioneered the standard AT-cut, 5 MHz, 1-inch diameter crystals for use in liquid

applications. The AT-cut quartz is chosen for its superior mechanical and piezoelectric properties,

and the angle of cut can be adjusted to obtain a zero temperature coefficient at a desired operating

temperature. The 1 inch diameter was chosen to allow enough distance between the active area

of the crystal and the mounting o-ring. This improves the overall stability of the crystal by

reducing the frequency changes due to mounting stress.

4.1.1 ELECTRODE

CONFIGURATION

Figure 8 below shows INFICON’s 1” crystal electrode patterns. The left figure shows the ½ inch

diameter front electrode (also called sensing electrode) with an extended electrode that wraps

around the edge of the crystal and extends into a semicircle shown in the top half of the right

figure. The lower half of the right figure shows the ¼ inch diameter rear electrode (also called

contact electrode).
This configuration enables both electrical contacts to be made on the backside of the crystal

allowing measurement in conductive liquids.
The oversized front electrode (½ inch in diameter as oppose to the ¼ inch diameter rear electrode)

was chosen to ensure a more consistence deposition across the active area of the crystal. The

exposed area of the front electrode is 0.212 in

2

(137 mm

2

), but the active oscillation region

(displacement area) is limited to the overlapping area of the front and rear electrodes (0.053 in

2

or

34.19 mm

2

).
