RQCM – RESEARCH QUARTZ CRYSTAL MICROBALANCE

GENERAL DESCRIPTION

1-4

1.2.2.2 Thermocouple

Input

Type:

Type “T” thermocouple

Temperature range:

0 to 371°C

Accuracy:

±

2°C + sensor error

1.2.2.3 RTD

Input

Type:

100 Ω Thin film platinum

Temperature range:

0 to 600°C

Accuracy:

±

4°C + sensor error

1.2.2.4 Thermistor

Input

Type:

100 KΩ

Temperature range:

0 to 150°C

Accuracy:

±

0.5°C + sensor error

1.2.3

I/O CARD (OPTIONAL)

Number of Discrete Inputs:

8, ground true 4.7KΩ pulled up to 5V

Number of Discrete Outputs:

8, SPST relays, 120VA, 2 A max.

1.2.4 COMMUNICATIONS

RS-232 serial port standard.
RS-485 serial port optional.
IEEE-488 optional.

1.2.5

FRONT PANEL INDICATORS

Communication Status LED’s
System Ready LED

1.2.6 POWER

REQUIREMENTS

100, 200, 220, 240 VAC @ 50/60Hz, 25 W

1.2.7 PHYSICAL
Size:

4” H (including feet) x 13” W x 9 ¾” D

Weight: 7 lbs.

Shipping Weight: 10 lbs.
