7. APPENDICES
DataFID Specifications
EPA Standards
Meets and exceeds US EPA Method 21 regulations
for fugitive emissions monitoring (LDAR)
LDAR Software Compatibility
Integrates with LeakDAS® Mobile and GuideWare
monitoring software
OperatingTemperature Range
32°F (0°C) to 122°F (50°C)
Operating Humidity Range
0 to 100% (non-condensing)
L x W x H
13 in. x 12 in. x 3 in.
(330 mm x 305 mm x 76.2 mm)
Weight:
11.0 lb. (5 kg).
Battery
15 hours operation, Nickel metal hydride (NiMH)
Keypad
Three menu keys
Display
Large 2.8 in. (7.1 cm) diagonal active area.
Backlight manually activated
Alarm
Audible at 85 dB, visual red LED on instrument
body
Connectivity
Bluetooth technology embedded for wireless data
connection
Detector
Flame ionization Detector (FID)
Response Time
90% of full scale in < 3 seconds
Operating Concentration Range
0.1 ppm to 50,000 ppm
Repeatability
±2%
Calibration Standards
Methane, hexane or propane
Fuel
99.999% UHP (Ultra High Purity) Hydrogen
Fuel Cylinder
Metal hydride, 70 liters capacity, 80 PSI cylinder
pressure, 70 hour discharge time / recharge 60
minutes
Fuel Cylinder Weight
1.9 lb. (0.8kg)
Fuel Cylinder Dimensions
6.5 in. (165 mm), 8 in. (203 mm) with coupling, 2 in.
diameter (51 mm)
Intrinsic Safety
Class 1, Division 1, Groups A,B,C & D (UL 913)
FCC
Class B digital device, pursuant to Subpart B, class
B of Part 15 of the FCC rules
