Menu Function Displays
Figure 12:. The DataFID Main Menu Display
The display reports instantaneous concentrations at all times when the flame is on. There are
four User modes: Logging Off, Interval, Location, and Method 21. In all four modes, the display
will report instantaneous concentrations.
The DataFID is designed for ease of use with a logically organized internal menu structure/user
interface.
The four submenus for the DataFID are expanded in Figures 13, 14, 15, and 16.
The DataFID has three soft keys, and they are located under the graphic LCD display. Each
display screen will always show the available functions of the soft keys.
Data log
Options
Menu
Download log to
PCD
Clear data log
Edit log interval
Verify BlueTooth
connection between
DataFID and the PC.
Hit ‘next’ to continue
Clear data log?
Yes or No
Enter New interval mode
Logging time (0-000 secs)
Sends logged data to
the PC via BlueTooth
connection
Yes clears data log
No leaves data intact
Figure 13: Data Log Options Menu
View Menu
DataFID
Setup
Data Log Options
Shutdown DataFID
meas
select
