074-578-P1A

58

DataFID Setup Functions

DataFID Setup functions are used to select the DataFID features (See Figure 14). There are
fourteen functions which can be set on the DataFID; Pump, Optional Air, Backlight, User
Mode, Clock, Date Format, Password, Language, Units of Measure, Blue Tooth,
Compound Selection, Select Cal Gas, Service Diagnostics, and Audio Control Menu.

Figure 14 shows a menu detailing the DataFID Setup functions. Press the MENU key in any
operating mode

to access “DataFID Setup” When prompted, enter the correct 4-digit password.

Once the correct password is entered, the user will be allowed to enter the DataFID Setup
menu.

Pump

The Pump function turns the pump on and off.

When the pump and the detector are off, the meter display will continue to read normally but the
instantaneous reading is at 0.0. Turn the pump and flame off when concentration
measurements are not necessary, and the DataFID will only be used for setup or reviewing
data. By operating the instrument with the pump and flame off when do not need them, battery
and hydrogen capacity will be conserved.

To turn on the pump:

1. Press the MENU sof

t key, “DataFID Setup”, press SELECT, “Pump”, press SELECT,

“On”, then press SELECT.

To turn off the pump:

2.

Press the MENU soft key, “DataFID Setup”, press SELECT, “Pump”, press SELECT,
“Off”, then press SELECT.

Backlight

The Backlight function is used to switch the backlighting on and off when there is insufficient
light to read the display.

To switch the Backlighting on and off:

1.

Press the MENU soft key and select “DataFID Setup”.

2. Select BACKLIGHT and then press the SELECT soft key. Press the DOWN ARROW

soft key to either turn the backlight on or off.

3. Press SELECT soft key to return to the main display.

To extend the operating life of the battery pack, turn the backlighting off when it is not required.

User Mode

User mode selects one of the four logging modes. The four logging modes are Logging Off,
Location, Interval, and Method 21 mode.
