074-578-P1A

45

enter password

1/02/09

location

14:45

Passcode

The DataFID allows setup data to be saved and accessed only through the use of a password.

Figure 19. Enter Password Display

When the DataFID Setup menu is selected, the next display will ask for the operator to enter a 4
digit code to access the Setup menu. The default passcode is 1111

User Modes

The four User Modes of the DataFID can be selected in the DataFID Setup menu by selecting
the User Mode option. The DataFID

’s default User mode is the Interval mode with a default

interval of 15 seconds. The user can select any one of the four options:

Location

Interval

Method 21

Logging Off


The DataFID can power up in the Interval, Location, Method 21, or Logging Off User Mode
depending on the mode that was set by the previous user prior to power down. While the user is
in one of these four modes, the resolution of the display changes with the magnitude of the
reading. A resolution of 0.01 ppm will be used for concentrations below 10 ppm, a resolution of
0.1 ppm will be used for concentrations between 10 ppm and 999.9 ppm, and a resolution of 1
ppm will be used above 1000 ppm.

Each of the four modes is described in the following sections.

Location Mode

Figure 20. Location Mode Display

Enter 4 digit code to access Setup menu

1111

done

35.7

ppm

Location Route Description

CAL: Meth

cancel edit menu

accept
