074-578-P1A

32

Figure 10. Hydrogen Fuel Cylinder Connected to Filling Station

Hydrogen
Tank
Valve

Warning: Do not
adjust this
regulator

Output
Valve

Red release
ring

Hydrogen fuel
cylinder
release ring
