Appendix, Specifications, 9 appendix – Heidolph Rotacool Mini User Manual
Page 39: 1 specifications
Appendix
1.01
Rotacool mini
37
9 Appendix
9.1 Specifications
Rotacool mini
Operating temperature range
[°C]
7
Temperature constancy
[K]
1
Cooling capacity in W with an ambient temperature of 20°C
at 7°C 370 W
Min. fill volume of cooling liquid
[l]
3
Expansion volume of cooling liquid
[l]
1
Antifreeze agent in the liquefier circulation (provided at factory)
R507
Pump delivery rate max.
[l/min]
12
Pump delivery pressure max.
[bar]
0,3
Cooling liquid connections
[mm]
M 16 x 1 / NW 8
Dimensions W x D x H
[mm]
255 x 450 x 400
Connection voltage
230V/50Hz or
115V/60Hz
Max. current consumption
[A]
2,5
Power consumption
[W]
500
Weight
[kg]
27
Protection class
IP 20
Permissible ambient conditions
5
–-40 °C at 80 % rel.
humidity
Table 9-1: Specifications
