E T C S e t u p G u i d e

Paradigm Repeater Module

Paradigm Repeater Module Setup Guide

Page 4 of 4

Electronic Theatre Controls, Inc.

Status Indicators

When power is applied to the ERn enclosure, the Paradigm repeater module LEDs located on the
front panel illuminate, indicating the status of the auxiliary power, LinkPower control network, and
connected stations.

The Aux Power and LinkPower LEDs indicate in green when the Paradigm station power module is
connected properly and auxiliary power and LinkPower are present. When there is an unbalance in
LinkPower the fault indicators illuminate. This condition typically means that the station wiring has
a fault, however it could mean a connected device is having an issue. A qualified technician should
inspect the system wire and terminations first, then proceed to disconnecting devices to pinpoint
the fault and correct it. The power supply will update the fault indicators automatically when the fault
condition is cleared.

• If the NET A line has a fault (is shorted or has leakage to ground), the Fault + LED lights.
• If the NET B line has a fault (is shorted or has leakage to ground), the Fault - LED lights.
• If neither fault LED is illuminated the data connections are properly installed and the stations

are receiving the data and power required for operation.
