8 • CE Source Four Zoom
English
Wiring and power information
A plug of at least 2.5 amp (220/240V) rating should be attached to
the luminaire's mains lead. The wires in the mains lead are
1.5mm 2 each and coloured in accordance with the following code:
HPL lamps
HPL lamps are tungsten halogen lamps.
Important: Verify that the HPL lamp you use is suitable for the
voltage at your facility. 115-, 120-, 230-, and 240-volt HPL lamps
are available. Operating HPL lamps above their rated voltage
reduces lamp life and can cause premature lamp failure.
Green and Yellow: Earth
Blue: Neutral
Brown: Live
WARNING! This luminaire must be earthed.
Current rating:
120V/5 amp maximum
240V/2.5 amp maximum
Operating frequency: 50/60Hz
WARNING! Do not use lamps other than the HPL in CE
Source Four Zoom luminaires. Use of lamps other than HPL
will void CE safety conformity and warranty.
Lamp code Watts Volts Color temp Ave rated life
HPL 575/230 575 230 3,200ºK 400 hour
HPL 575/230X 575 230 3,050ºK 1500 hour
HPL 575/240 575 240 3,200ºK 400 hours
HPL 575/240X 575 240 3,050ºK 1500 hour
HPL 550/77 550 77 3,250ºK 300 hour
HPL 550/77X 550 77 3,050ºK 2,000 hour
HPL 575/115 575 115 3,250ºK 300 hour
HPL 575/115X 575 115 3,050ºK 1,000 hour
HPL 575/120 575 120 3,250ºK 300 hour
t 180
°
c
Euro.
American
