2.2 HY10L Mixing Instructions
It is recommended that the fluidity be measured on every batch (bag) mixed until the user becomes familiar with the system.
Depending on the temperature, the mix size, and the specific application, more or less water may be necessary. Additionally,
the fluidity should be checked at the beginning of each shift and for every NEW LOT of HY10L, or as required by the engineer.
Lot numbers are identified on each bag.
!!CAUTION!!
DO NOT USE MORE THAN 13.5% WATER by weight (0.8 gallons or 3L per 50 lb. (22.7 kg) bag) or obtain a flow template
reading of greater than 6-1/2” (165 mm) as this will result in insufficient strength gain. A flow template reading of below 5”
(127 mm) will make pumping of the HY10L difficult and will reduce the performance of the system.
2.3 Mixing Steps: (See Cautions)
1. Place all the mixing water into the mixing bowl. Add only enough water to meet the flow template requirements.
2. While blending with the mixer, slowly add the HY10L into the water until the bag is empty.
3. MIX THOROUGHLY FOR A MINIMUM OF 5 MINUTES. Longer mix times may be necessary to achieve a uniform
blend. Improper mixing may result in poor strength, due to unevenly mixed materials. Use ONLY full bags of HY10L
for each batch made.
4. To assure a uniform blend, periodically during mixing scrape down the sides of the mixing bucket. The useful
working time of the HY10L is shown in Figure 1 in the Hot and Cold Weather Grouting Instructions section. The
potlife may vary considerably depending on the temperature.
!!CAUTION!!
If any of the items listed below occurs, the material will not develop the required strength and the batch MUST be discarded
and fresh material MUST be used.
1. Under no conditions should the HY10L be retempered by adding additional water once it has stiffened.
2. Once mixed, if the fluidity of the grout is greater than 6-1/2” (165 mm) as measured on the flow template,
DO NOT ADD ADDITIONAL DRY HY10L to reduce the fluidity.
3. DO NOT ADD cement, sand or any additives or admixtures to the HY10L as this will adversely affect the properties.
4. A mechanical mixer MUST be used to mix the HY10L.
DO NOT MIX BY HAND. Contact ERICO for a list of suitable mixers and accessories.
LENTON ® INTERLOK Warranty and Conditions:
Contact ERICO for specific terms of the warranty.
Storage:
HY10L should be stored in a cool, dry environment. It is recommended that the HY10L be stored indoors to maintain maximum
shelf life and physical properties. If the bag is damaged or becomes wet, the HY10L must be discarded.
Shelf Life:
HY10L’s shelf life is 12 months from the manufacturing date printed on the bag, when stored in accordance with ERICO
guidelines. HY10L which has been stored beyond 12 months from the manufacturing date or that is beyond the expiration
date should be discarded.
