Job Site Grouting
2.1 Quantity of LENTON ® INTERLOK Splices per Bag of HY10L
HY10L is provided in 50 pound (22.7 Kg) bags
The values given in the above table are estimates only, assuming maximum rebar embedment in the coupler.
Actual values will vary depending on job site practice and conditions.
It is important when determining the amount of grout for the particular application to consider adding an additional
10% during hot and cold weather grouting. This is particularly important during hot weather grouting where there
may be more grout discarded due to the reduced working times and shorter potlife.
For pump fill applications it is important to include the volumes of the inlet and outlet tubes in the determination.
These volumes become significant in applications where the precast members are unusually thick and the PVC inlet
and outlet tubes become long.
Rebar Size
Coupler
Part No.
Coupler
Article No.
Theoretical Volume of Grout
Required to Fill Coupler
Estimated Number
of Splices per 50 lb.
(22.7 Kg) Bag in-lb Metric Canadian Quarts Liters
#5 16mm 15M LK5 145575 1/3 0.33 24
#6 20mm 20M LK6 145580 1/3 0.31 25
#7 22mm --- LK7 145585 1/3 0.30 26
#8 25mm 25M LK8 145590 3/8 0.37 21
#9 28mm 30M LK9 145595 1/2 0.45 17
#10 32mm --- LK10 145600 5/8 0.57 13.5
#11 36mm 35M LK11 145605 3/4 0.67 11.5
--- 40mm --- LK40 145610 1-1/4 1.13 7
#14 43mm 45M LKT14 145611 1-1/8 1.07 7
--- 50mm --- LKT50 145615 2 1.93 4
#18 57mm 55M LKT18 145620 1-3/4 1.66 4.5
