Imperial units – ERICO LENTON INTERLOK Rebar Splicing System User Manual
Page 10
4
www.erico.com
1.3 Coupler Dimensions and Determining Cut
Length of Reinforcing Steel – Transitions – Imperial Units
* “X” Min. Type 1 and “Y” Min. Type 1 will develop 125% of the specified yield strength of the rebar in tension and compression ( 125% fy ).
** “X” Min. Type 2 and “Y” Min. Type 2 meet Type 1 and will develop the specified tensile strength of the rebar in tension ( fu ).
+ Indicates threaded rebar size
Contact ERICO for rebar sizes not listed.
Imperial Units:
Rebar Size
in-lb
Coupler
Part No.
Condition
“A”
“B”
“C”
“D”
“E”
Reference
“X”
Max.
“X” Min.
Type 1*
“X” Min.
Type 2**
“Y”
Max.
“Y” Min.
Type 1*
“Y” Min.
Type 2**
#6 to #5
+
LK65
Pump
7-13/16”
2-9/16”
7/8”
1-7/8”
13/16”
6-1/8”
5-1/4”
5-3/8”
6-1/8”
5-1/4”
5-1/2”
#6
+
to #5
LK6
Gravity
7-13/16”
2-9/16”
1-1/8”
1-7/8”
9/16”
6-1/8”
5-1/4”
5-3/8”
6-1/8”
5-1/4”
5-1/2”
#7 to #6
+
LK76
Pump
7-13/16”
2-9/16”
1-1/8”
1-7/8”
9/16”
6-1/8”
5-1/4”
6-1/8”
5-1/4”
5-3/8”
#7
+
to #6
LK7
Gravity
7-13/16”
2-9/16”
1-1/4”
1-7/8”
7/16”
6-1/8”
5-1/4”
6-1/8”
5-1/4”
5-3/8”
#8 to #7
+
LK87
Pump
8-5/8”
2-11/16”
1-1/4”
2”
3/8”
7”
6”
6-1/8”
5-1/4”
#8
+
to #7
LK8
Gravity
8-5/8”
2-11/16”
1-3/8”
2”
1/4”
7”
6”
7”
5-1/4”
#9 to #8
+
LK98
Pump
9-3/4”
2-13/16”
1-3/8”
2-1/8”
3/8”
8”
6-7/8”
7”
6”
#9
+
to #8
LK9
Gravity
9-3/4”
2-13/16”
1-1/2”
2-1/8”
1/4”
8”
6-7/8”
8”
6”
#10 to #9
+
LK109
Pump
10-13/16”
3”
1-1/2”
2-5/16”
5/16”
9”
7-3/4”
8”
6-7/8”
#10
+
to #9
LK10
Gravity
10-13/16”
3”
1-9/16”
2-5/16”
1/4”
9”
7-3/4”
9”
6-7/8”
#11 to #10
+
LK1110
Pump
11-15/16”
3-1/8”
1-9/16”
2-7/16”
1/2”
9-7/8”
8-1/2”
9”
7-3/4”
#11
+
to #10
LK11
Gravity
11-15/16”
3-1/8”
1-11/16”
2-7/16”
3/8”
9-7/8”
8-1/2”
9-7/8”
7-3/4”
#14 to #11
+
LK1411
Pump
15-3/16”
3-11/16” 1-11/16”
2-3/4”
3/4”
12-3/4”
11”
9-7/8”
8-1/2”
#14
+
to #11
LKT14
Gravity
15-3/16”
3-11/16”
2-1/8”
2-3/4”
5/16”
12-3/4”
11”
12-3/4”
8-1/2”
#18 to #14
+
LK1814T
Pump
20-5/16”
4-1/2”
2-1/8”
3-1/4”
1-3/16”
17”
14-3/4”
12-3/4”
11”
#18
+
to #14
LKT18
Gravity
20-5/16”
4-1/2”
2-3/4”
3-1/4”
9/16”
17”
14-3/4”
17”
11”
To Determine Typical Cut Length of
Reinforcing Steel:
Maximum Cut Length
Gravity Condition =
[Overall Panel Height - E]
+ Sealing Mortar Height
Pump Condition =
[Overall Panel Height - E - Xmax]
+ Ymax + Sealing Mortar Height
Minimum Cut Length =
Maximum Cut Length - 1 Bar Diameter
Dowel Length =
X + Sealing Mortar Height
Y + Sealing Mortar Height
Note: For last lift, reduce cut length as
determined by design requirements.
