Metric units – ERICO LENTON INTERLOK Rebar Splicing System User Manual
Page 11
5
www.erico.com
1.3 Coupler Dimensions and Determining Cut
Length of Reinforcing Steel – Transitions – Metric Units
* “X” Min. Type 1 and “Y” Min. Type 1 will develop 125% of the specified yield strength of the rebar in tension and compression ( 125% fy ).
** “X” Min. Type 2 and “Y” Min. Type 2 meet Type 1 and will develop the specified tensile strength of the rebar in tension ( fu ).
+ Indicates threaded rebar size
Contact ERICO for rebar sizes not listed.
Metric Units:
Rebar Size
mm
Coupler
Part No.
Coupler
Article
No.
Condition
“A”
mm
“B”
mm
“C”
mm
“D”
mm
“E”
Reference
mm
“X”
Max.
mm
“X” Min.
Type 1*
mm
“X” Min.
Type 2**
mm
“Y”
Max.
mm
“Y” Min.
Type 1*
mm
“Y” Min.
Type 2**
mm
20 to 16
+
LK65
Call ERICO
Pump
199
65
22
48
21
156
134
136
156
134
140
20
+
to 16
LK6
Call ERICO
Gravity
199
65
29
48
14
156
134
136
156
134
140
22 to 20
+
LK76
Call ERICO
Pump
199
65
29
48
14
156
134
156
134
136
22
+
to 20
LK7
Call ERICO
Gravity
199
65
32
48
11
156
134
156
134
136
25 to 22
+
LK87
Call ERICO
Pump
219
68
32
51
9
178
153
156
134
25
+
to 22
LK8
Call ERICO
Gravity
219
68
35
51
6
178
153
178
134
28 to 25
+
LK98
Call ERICO
Pump
248
72
35
54
10
203
175
178
153
28
+
to 25
LK9
145595
Gravity
248
72
38
54
7
203
175
203
153
32 to 28
+
LK109
Call ERICO
Pump
275
76
38
59
8
229
197
203
175
32
+
to 28
LK10
145600
Gravity
275
76
40
59
6
229
197
229
175
36 to 32
+
LK1110
Call ERICO
Pump
303
79
40
62
12
251
215
229
197
36
+
to 32
LK11
145605
Gravity
303
79
43
62
9
251
215
251
197
40 to 36
+
LK1411
Call ERICO
Pump
386
94
43
70
19
324
284
318
251
215
40
+
to 36
LK40
145610
Gravity
386
94
58
70
4
324
284
318
324
215
43 to 36
+
LK1411
Call ERICO
Pump
386
94
43
70
19
324
281
251
215
43
+
to 36
LK14
Call ERICO
Gravity
386
94
54
70
8
324
281
324
215
50 to 40
+
LK5040
Call ERICO
Pump
516
114
58
83
26
432
382
426
324
284
318
50
+
to 40
LKT50
145615
Gravity
516
114
71
83
13
432
382
426
432
284
318
57 to 43
+
LK1814T
Call ERICO
Pump
516
114
54
83
30
432
375
324
281
57
+
to 43
LKT18
145620
Gravity
516
114
72
83
14
432
375
432
281
To Determine Typical Cut Length of
Reinforcing Steel:
Maximum Cut Length
Gravity Condition =
[Overall Panel Height - E]
+ Sealing Mortar Height
Pump Condition =
[Overall Panel Height - E - Xmax]
+ Ymax + Sealing Mortar Height
Minimum Cut Length =
Maximum Cut Length - 1 Bar Diameter
Dowel Length =
X + Sealing Mortar Height
Y + Sealing Mortar Height
Note: For last lift, reduce cut length as
determined by design requirements.
