The cadweld, One shot process – ERICO CADWELD Exothermic Welding User Manual
Page 33
Fig. 11
Quickly pour the loose welding material powder into
the CADWELD
®
ONE SHOT mold.
Fig. 12
Place the cover on the top of the CADWELD ONE SHOT.
Fig. 13
The bottom of the tube contains compressed material
(starting material). Tap the bottom of the tube a
couple of times to loosen this material.
Fig. 14
Pour the starting material onto the CADWELD ONE
SHOT cover.
NOTE: Welding material is an exothermic
mixture and reacts to produce hot molten
material with temperatures in excess of 2500
degrees Fahrenheit (1400 degrees Celsius) and
a localized release of smoke. Avoid direct eye
contact with “flash” of light from ignition of
starting material. Avoid inhalation of smoke/
fumes.
31
The CADWELD
®
ONE SHOT Process
